Bayreuth (EDQD) is an aerodrome near Bindlach, published in the official Aeronautical Information Publication (AIP). It has one runway. AIP:Aero links its official AIP entry together with runway, frequency and current weather information.
AIRAC October 1, 2026
We send you a PDF with weather, NOTAMs, runways, frequencies and chart links for up to three aerodromes of your route.
Shown length is the physical runway dimension - see glossary
Read automatically from the official AIP page image by text recognition (OCR) and may contain reading errors. Always verify against the current AIP before flight.
1 | Cargo-handling facilities O/R 2| Fuel/oil types AVGAS 100 LL, Jet A1/ 80, 100, D-80, D-100, Multigrade SAE 15W50 3| Fuelling facilities/capacity AVGAS 100 LL: Fuel pumps Jet Al: Fuel pumps [...] 5| Hangar space for visiting aircraft O/R 6| Repair facilities for visiting aircraft Air Service Bayreuth Tel.: +49 921 5074 3989 e-mail: info@air-service-bayreuth.de 7| Remarks Nil EDQD
1] Hotels Bayreuth, Bindlach 2| Restaurants On Top, Tel.: +49 9208 5709 135 [...] 3| Transportation Taxi, bus 4| Medical facilities - 5| Bank and Post Office 6| Tourist Office 7| Remarks Nil EDQD
1] AD category for fire fighting RFFS not AVBL; CAT1 und CAT 2 OR, CAT 3 PPR, O/T PPR 2| Rescue equipment Fire fighting vehicle: IVECO-Magirus 180/25 AHW 3| Capability for removal of disabled aircraft 4| Remarks NIL EDQD
Runway surface condition assessment and reporting and snow plan 1] Type(s) of clearing equipment 1 snow plough, 1 spreader, 1 airblast sweeper, 1 rotary snow plough 2| Clearance priorities 3| Use of material for movement area surface treatment NIL 4| Specially prepared winter runways Not applicable 5| Remarks Seasonal availability unrestricted AMDT 06/24 © DFS Deutsche Flugsicherung GmbH LUFTFAHRTHANDBUCH DEUTSCHLAND AD 2 EDOD 1-3 AIP GERMANY 28 NOV 2024 EDQD
Buying or selling an aircraft? Trade:Aero - Europe's largest aircraft marketplace
Browse aircraft for sale in Germany on Trade:Aero - the marketplace for buying and selling aircraft.
Official area forecast for VFR flights in Germany by the German Meteorological Service (DWD), issued several times a day with a forecast in 2-hour steps.
Current GAFOR rating per period: see the official source below.
Area 57 · Oberfranken · GAFOR area Süd
Deutscher Wetterdienst: Die auf dieser Internetseite bereitgestellten Flugwetterprodukte des DWD dürfen ausschließlich zur individuellen meteorologischen Flugvorbereitung genutzt werden.
GAFOR is an advisory forecast - always check the official source before flight.
Registration may be required
Open Flight Maps VFR chart (PDF)
Complementary VFR chart, not the official AIP.
· OpenStreetMap
Open now - closes 16:00Zper AIP AD 2.3
Confirm via NOTAM / current AIP before flight.
Frequencies read automatically from the AIP by text recognition - may contain read errors. Verify against the current AIP before flight.
1| Designation, surface and strength of aprons APRON 1: ASPH APRON 2: ASPH APRON 3: ASPH APRON 4: ASPH MAIN APRON: ASPH 2| Designation, width, surface and strength of taxiways TWY C: 10 m; ASPH TWY A, B, D: 7.5m; ASPH 3] Altimeter checkpoint location and elevation 4| VOR checkpoints NIL 5| INS checkpoints NIL 6| Remarks NIL EDQD
1| Use of aircraft stand ID signs, TWY guide lines and visual NIL docking/parking guidance system at aircraft stands 2| RWY and TWY markings and LGT RWY designation, RWY centreline, THR marking TWY centre line, taxi holding position. RWY, TWY lighted. 3] Stop bars 4| Remarks TWY indicators EDQD
Refer to AD 2 EDQD 2-11 AERODROME OBSTACLE CHART - ICAO TYPE A RWY 06/24 EDQD
RWY centre line LGT | RWY edge APCH LGT LEN, LGT RWY end type THR LGT VASIS spacing LEN Spacing, LGT SWY LGT RWY LEN colour (MEHT) TDZLGT colour, colour colour LEN (M) Designator INTST WBAR PAPI LEN INTST INTST WBAR colour 1 2 3 4 5 6 7 8 9 SALS 06 LIH G 3.0° . w R . | Sequence flash LIH 14.00 ft LIH LIH available SALS 24 LIH G 45° . w R . | Sequence flash LIH 9.00 ft LIH LIH available Remarks 10 06 Nil 24 Nil EDQD
1 | ABN/IBN location, characteristics and hours of operation ABN white/white on TWR 2 | LOI location and LGT See Chart AD 2 EDQD 2-5 Anemometer location and LGT 3 | TWY edge and centre line LGT TWY edge lights of TWYs: BLIH 4 | Secondary power supply including switch-over time Available / 30 SEC 5 | Remarks Nil EDQD
1 | Coordinates TLOF or THR of FATO NIL Geoid undulation 2 | TLOF and/or FATO elevation m/ft NIL 3 | TLOF and FATO area dimensions, surface type, bearing NIL strength and marking 4 | True BRG of FATO NIL 5 | Declared distance available NIL 6 | APP and FATO lighting NIL 7 | Remarks RWY 06/24 © DFS Deutsche Flugsicherung GmbH AMDT 08/25 LUFTFAHRTHANDBUCH DEUTSCHLAND AD 2 EDQD 1-7 AIP GERMANY Effective: 05 SEP 2024 EDQD
NIL EDQD
Charts related to the aerodrome Page Type of chart AD 2 EDQD 2-5 AERODROME CHART - ICAO AD 2 EDQD 2-11 AERODROME OBSTACLE CHART - ICAO TYPE A RWY 06/24 | AD 2 EDQD 3-1-1 STANDARD ARRIVAL CHART - INSTRUMENT (STAR) - ICAO RNAV RWY 06 AD 2 EDOD 4-6-1 INSTRUMENT APPROACH CHART - ICAO RNAV (GPS) RWY 06 AD 2 EDOD 5-7-1 STANDARD DEPARTURE CHART - INSTRUMENT (SID) - ICAO RNAV (GPS) RWY 06 AD 2 EDOD 5-7-4 STANDARD DEPARTURE CHART - INSTRUMENT (SID) - ICAO RNAV (GPS) RWY 24 EDQD
Visual segment surface (VSS) penetration NIL © DFS Deutsche Flugsicherung GmbH AIRAC AMDT 09/24
PPR-/Service-Request über das aerops-Self-Service-Portal.
On AIP:Aero
Ratings by Google
The authority publishes no separate chart PDF for this aerodrome. The AIP button above opens its official AIP entry.
According to the AIP, Bayreuth EDQD has: 06/24 3392 × 98 ft (1034 × 30 m). Lengths in feet, metres in brackets.
Aerodrome dataThe aerodrome elevation of Bayreuth EDQD is 1600 ft (488 m) above MSL.
Aerodrome dataRadio frequencies of Bayreuth EDQD: ATIS 119.560 · APP 129.525 · AFIS 127.530. Check them against the current AIP and the NOTAMs before you fly.
incl. 19% VAT
Example price, may vary - calculate the exact amount with the aerodrome.
Frame: 08:20 UTC
Weather radar data © RainViewer · © OpenFreeMap · © OpenStreetMap
Scan time: 08:00 UTC
Fuel reported at Bayreuth EDQD: AVGAS, Jet A-1. Confirm availability before you fly.
Aerodrome dataLanding fees at Bayreuth EDQD start at 4.17 EUR (<= 0.6 t MTOW). An indicative figure: the exact price depends on the aircraft and options, so confirm it with the aerodrome.
Aerodrome dataNOTAMs via the FAA, informational only - check the official pre-flight briefing.
C3623/26 NOTAMR C2145/26 Q) EDMM/QPOCH/I /NBO/A /000/999/4959N01138E005 A) EDQD B) 2608140627 C) 2611122359EST E) LPV APCH OPERATIONAL. OCA(H) VALUES RAISED: LPV RWY 06 WITH MISSED APCH CLIMB GRADIENT 5.0PCT: A 1870 (285), B 1890 (305)FT. LPV RWY 06 WITH MISSED APCH CLIMB GRADIENT 2.5PCT: A 2160 (575), B 2175 (590)FT. DUE TO INADEQUATE PROTECTION PROVIDED IN MISSED APCH SEGMENT FOR SOME NAV SYSTEMS AUTHORISED FOR LPV OPS.
C0214/26 NOTAMR C0177/26 Q) EDMM/QPICH/I /NBO/A /000/999/4959N01138E005 A) EDQD B) 2601090909 C) PERM E) CHANGES TO RNP APCH PROC DUE TO A NEW WINDTURBINE: AMEND ALTITUDE CONSTRAINT OVER VADKO AND VADKO MINIMUM HOLDING ALTITUDE TO READ 4100FT MSL. AMEND MISSED APCH TO READ CROSS VADKO AT 4100FT MSL. REF AIP AD 2 EDQD 4-6-1 DATED 31 OCT 2024, 4-6-2 EFF 05 SEP 2024.
C0213/26 NOTAMR C0176/26 Q) EDMM/QPACH/I /NBO/A /000/999/4959N01138E005 A) EDQD B) 2601090905 C) PERM E) CHANGES TO ALL STAR DUE TO A NEW WINDTURBINE, AMEND ALTITUDE CONSTRAINT OVER VADKO AND VADKO MINIMUM HOLDING ALTITUDE TO READ 4100FT MSL. REF AIP AD 2 EDQD 3-1-1 DATED 27 NOV 2025 AND 3-1-2 EFF 05 SEP 2024.
