Free VFR approach charts (AIP), NOTAMs and weather (METAR/TAF) for Speyer EDRY - plus aerodrome data and the current AIRAC cycle.
The free German Aeronautical Information Publication AIP is now available as a basic version from Deutsche Flugsicherung (DFS), but without a search function. Our site makes it easier to find airfields, but we do not accept any liability for the accuracy or timeliness of the AIP (Aeronautical Information Publication), as it is not published by us. We only link to the respective approach charts.
Speyer (EDRY) is an aerodrome near Speyer, published in the official Aeronautical Information Publication (AIP). It has 2 runways. AIP:Aero links its official AIP entry together with runway, frequency and current weather information.
AIRAC October 1, 2026
Always check the field's AIP GEN 1.2.
There is an app2drive station directly at this aerodrome.
Flugplatz Speyer/Ludwigshafen, Joachim-Becher-Straße 2, Speyer
Availability and prices are shown by app2drive.
We send you a PDF with weather, NOTAMs, runways, frequencies and chart links for up to three aerodromes of your route.
Read automatically from the official AIP page image by text recognition (OCR) and may contain reading errors. Always verify against the current AIP before flight.
1| Cargo-handling facilities 2| Fuel/oil types AVGAS 100 LL, Jet A1, MOGAS/ 80, 100, D80, D100, DM 15W50 3| Fuelling facilities/capacity AVGAS 100 LL: fuel station Jet Al: 2 fuel stations (pressure fueling and ovenwing refueling AVBL) MOGAS: fuel station 4 | De-icing facilities no de-icing AVBL, limited number of heated hangar spaces AVBL PPR 5| Hangar space for visiting aircraft O/R 6| Repair facilities for visiting aircraft Air Service Krüger Joachim-Becher-StraBe 2, 67346 Speyer Hangar Zulu LBA-Nr. DE.MF.0054 Tel.: +49 160 94489546 7| Remarks Nil EDRY
1| Hotels Speyer 2| Restaurants Speyer 3| Transportation Taxi, rent-a-car 4| Medical facilities 5| Bank and Post Office - [...] 7| Remarks Nil EDRY
1| AD category for fire fighting 3, (PPR up to CAT 6)RFFS according ICAO Annex 14 and NIL 2023-1-2792 2| Rescue equipment 3| Capability for removal of disabled aircraft Limited 4| Remarks NIL EDRY
Runway surface condition assessment and reporting and snow plan 1| Type(s) of clearing equipment 1 vehicle (capable of sweeping, blowing, pushing) 1 tractor (capable of spraying) 2 | Clearance priorities RW and appropriate TWYs pron Remaining parts of movement area 3| Use of material for movement area surface treatment Chemical treatment (Ice Breaker) 4| Specially prepared winter runways Not applicable 5| Remarks Nil AMDT 06/26 © DFS Deutsche Flugsicherung GmbH LUFTFAHRTHANDBUCH DEUTSCHLAND AIP GERMANY AD 2 EDRY 1-3 11 JUN 2026 EDRY
There is an aviation museum at this aerodrome.
Opening hours and admission are published by the museum.
Buying or selling an aircraft? Trade:Aero - Europe's largest aircraft marketplace
Browse aircraft for sale in Germany on Trade:Aero - the marketplace for buying and selling aircraft.
Official area forecast for VFR flights in Germany by the German Meteorological Service (DWD), issued several times a day with a forecast in 2-hour steps.
Current GAFOR rating per period: see the official source below.
Area 51 · Mittlerer Oberrheingraben · GAFOR area Mitte
Deutscher Wetterdienst: Die auf dieser Internetseite bereitgestellten Flugwetterprodukte des DWD dürfen ausschließlich zur individuellen meteorologischen Flugvorbereitung genutzt werden.
GAFOR is an advisory forecast - always check the official source before flight.
Registration may be required
Open Flight Maps VFR chart (PDF)
Complementary VFR chart, not the official AIP.
· OpenStreetMap
Open now - closes 18:00Zper AIP AD 2.3
Confirm via NOTAM / current AIP before flight.
Frequencies read automatically from the AIP by text recognition - may contain read errors. Verify against the current AIP before flight.
1 | Designation, surface and strength of aprons APRON 5: PAV GRASS APRON: GRASS MAIN APRON (Positions 1- 4): ASPH 2| Designation, width, surface and strength of taxiways TWY C: 14.5 m; ASPH TWY F: 12 m; ASPH TWYE,H, S: 10.5 m; ASPH TWY D: 8 m; ASPH TWY A, B, G, J: 7.5 m; ASPH Altimeter checkpoint location and elevation THR 16: 312 ft, THR 34: 319 ft VOR checkpoints NIL INS checkpoints NIL [...] Remarks NIL EDRY
1| Use of aircraft stand ID signs, TWY guide lines and visual docking/parking guidance system at aircraft stands NIL 2| RWY and TWY markings and LGT RWY designation, THR markings, taxi holding position RWY, TWY lighted. 3| Stop bars 4| Remarks TWY signs EDRY
Not applicable EDRY
RWY centre line LGT | RWY edge APCHLGT LEN, LGT RWY end type THRLGT VASIS spacing LEN Spacing, LGT SWY LGT RWY LEN colour (MEHT) TDZLGT colour, colour colour LEN (M) Designator INTST WBAR PAPI LEN INTST INTST WBAR colour 1 2 3 4 5 6 7 8 9 G Ww R 16 ° LIH . LIH UH - G Ww R [...] Remarks 10 16 Nil 34 Nil EDRY
1 | ABN/IBN location, characteristics and hours of operation ABN white/white on TWR 2 | LDI location and LGT See Chart AD 2 EDRY 2-5 Anemometer location and LGT Wind direction indicator 3 | TWY edge and centre line LGT TWY edge lights of TWYs: BLIL 4 | Secondary power supply including switch-over time - 5 | Remarks Nil EDRY
1 | Coordinates TLOF or THR of FATO NIL Geoid undulation TLOF and/or FATO elevation m/ft NIL 3 | TLOF and FATO area dimensions, surface type, bearing NIL strength and marking 4 | True BRG of FATO NIL 5 | Declared distance available NIL 6 | APP and FATO lighting NIL 7 | Remarks Not specified; according to directions from TWR EDRY
1 | Designation and lateral limits RMZ 2 | Vertical limits 1000 ft AGL 3 | Airspace classification G [...] Language(s) English, German 5 | Transition altitude 5000 ft MSL 6 | Hours of applicability NIL 7 | Remarks For detailed airspace description see ENR 2.2 © DFS Deutsche Flugsicherung GmbH AMDT 06/26 LUFTFAHRTHANDBUCH DEUTSCHLAND AD 2 EDRY 1-7 AIP GERMANY 23 JAN 2025 EDRY
NIL EDRY
NIL EDRY
Charts related to the aerodrome Page Type of chart AD2 EDRY 4-6-1 INSTRUMENT APPROACH CHART - ICAO RNP Z RWY 16 AD 2 EDRY 4-6-2 INSTRUMENT APPROACH CHART - ICAO RNP Y RWY 16 AD 2 EORY 4-6-6 INSTRUMENT APPROACH CHART - ICAO RNP Z RWY 34 AD 2 EORY 4-6-7 INSTRUMENT APPROACH CHART - ICAO RNP Y RWY 34 EDRY
Visual segment surface (VSS) penetration NIL © DFS Deutsche Flugsicherung GmbH AMDT 01/25
PPR-/Service-Request über das aerops-Self-Service-Portal.
On AIP:Aero
The authority publishes no separate chart PDF for this aerodrome. The AIP button above opens its official AIP entry.
According to the AIP, Speyer EDRY has: 16/34 5501 × 98 ft (1677 × 30 m) · 16R/34L 3281 × 98 ft (1000 × 30 m). Lengths in feet, metres in brackets.
Aerodrome dataThe aerodrome elevation of Speyer EDRY is 312 ft (95 m) above MSL.
Aerodrome dataRadio frequencies of Speyer EDRY: ATIS 129.280 · APP 129.355 · AFIS 118.080. Check them against the current AIP and the NOTAMs before you fly.
incl. 19% VAT
Example price, may vary - calculate the exact amount with the aerodrome.
Frame: 08:50 UTC
Weather radar data © RainViewer · © OpenFreeMap · © OpenStreetMap
Scan time: 08:20 UTC
Fuel reported at Speyer EDRY: Super PLUS, AVGAS, Jet A-1. Confirm availability before you fly.
Aerodrome dataLanding fees at Speyer EDRY start at 11.59 EUR (<= 1.2 t MTOW). An indicative figure: the exact price depends on the aircraft and options, so confirm it with the aerodrome.
Aerodrome dataYes, the aerodrome is listed as an airport of entry. Hours and prior notice are in GEN 1.2 of the national AIP.
Border crossing & customsNOTAMs via the FAA, informational only - check the official pre-flight briefing.
C4288/26 NOTAMR C2894/26 Q) EDGG/QMRLC/IV/NBO/A /000/999/4918N00827E005 A) EDRY B) 2609301426 C) 2612301425EST E) GRASS RWY 16/34 CLSD.
C3747/26 NOTAMN Q) EDGG/QPIAU/I /NBO/A /000/999/4918N00827E005 A) EDRY B) 2608231309 C) 2611122359EST E) ALL LPV APCH SUSPENDED DUE TO INADEQUATE PROTECTION PROVIDED IN MISSED APCH SEGMENT FOR SOME NAV SYSTEMS AUTHORISED FOR LPV OPS.
